HOLLY MODEL 1931

Carburetor

Illustrated Parts Break Down

1) Choke Plate Assy.

2) Choke Shaft Assy.

3) Throttle Stop
Screw

4) Metering Block
Scr. & L.W.

5) Float Bowl Scr.
& L.W.

6) Choke Plate
Screw & L.W.

7) Throttle Plate
Scr. & L.W

8) Choke Piston
Adjusting Screw

9) Fast Idle Cam
Screw
10) Metering Block
Scr. & L.W.

11) Float Shaft
Brkt. Scr. & L.W.

12) Vent Rod
Retainer Screw

13) Throttle
Adjusting Screw

14) Choke Piston
Plug

15) Fuel Inlet Seat
Gasket

16) Flange Gasket

17) Fuel Bowl
Gasket

18) Throttle Plate

19) Throttle Lever
& Shaft Assy.
20) Throttle Shaft
Bearing

21) Idle Adjusting
Needle

22) Float & Hinge
Assy.

23) Float Shaft

24) Fuel Inlet
Needle & Seat
Assy

25) Main Jet

26) Mechanical
Vent Valve

27) Pump
Diaphragm Assy.
Complete

28) Pump
Operating Link
29) Float Bowl

30) Metering Block
& Plugs Assy.

31) Power Valve
Retainer

32) Idle Adjusting
Needle Spring

33) Fast Idle Screw
Spring

34) Mechanical Vent
Spring

35) Pump Drive
Spring

36) Throttle Stop
Screw Spring

37) Fast Idle Cam

38) Fast Idle Rod

face="Verdana, Arial, Helvetica, sans-serif" size="4">HOLLY MODEL 1931 Exploded view
41) Mechanical Vent
Rod Ret. Washer

42) Vent Rod
Operating Washer

43) Fast Idle Rod
Washer

44) Mechanical Vent
Spring Washer

39) Mechanical Vent
Rod

40) Choke Piston &
Link Assy.

45) Pump Link
Retainer
46) Choke Piston
Link Cotter
       Pin

47) Float Shaft
Retaining Bracket

48) Pump
Operating Lever

49) Pump
Operating
Lever Retainer

 50) Choke
Thermostat Hsg.
Assy.

51) Choke Lever
52) Choke Therm.
Cov. Retainer Scr.

53) Choke Lever
Screw

54) Dashpot Bracket
Screw

55) Thermostat
Housing Gasket

56) Pump Push Rod
Sleeve Ball

57) Thermostat
Cover Retainer

58) Pump Operating
Spring

59) Throttle Return
Spring
60) Dashpot Nut

61) Pump Push Rod
Sleeve

62) Dashpot Bracket
Lock Washer

63) Pump Operating
Link Washer

64) Thermostat &
Cover Assy.

65) Dashpot
Bracket

66) Dashpot
Assembly


The illustrated parts break down illustrates individual part placement in the assembly.
